EQUIPMENT: T1200
PUBLICATION: 19A-4-O
ISSUE No. & DATE: 3 06/09
© 2006 Tyco Safety Products PAGE 7 of 13
Registered Company: Thorn Security Ltd. Registered Office: Dunhams Lane Letchworth Garden City Hertfordshire SG6 1BE
4. T1200 User Controls – Disablement
and Test Conditions.
4.1 To Disable/Enable any Zone or
Zones.
• To Access disable/enable mode:
o Turn the Access Controls Keyswitch on the
panel door to position “1”.
o Press the Select On/Off button to enter the
Select Mode.
o The Select On LED will light.
o The cursor indication will pulse the yellow
Zone 1 fault LED.
• To select the zone:
Use the Select ↓ button to move the cursor
indication down through the fault LEDs until it
pulses on the required zone. [The Select ↑
button moves the cursor up].
• To disable the selected zone:
o Press the Disable button to disable the
selected zone.
o The zone fault/disabled LED will change to
the “On-flash” indication while the cursor
is on it, changing to steady if the cursor is
moved on.
o The general Disablement LED will light.
• To enable the selected zone:
o Press the Enable button to enable the
selected zone.
o The zone fault/disabled LED will change to
the “Off-flash” indication while the cursor
is on it, changing to off if the cursor is
moved on.
o The general Disablement LED will be
cleared if no other disablements are present.
• To quit the disable/enable mode:
o To exit the Select Mode, press the Select
On/Off button.
o The Select On LED will clear.
o The cursor indication will clear.
o Set the Access Controls Keyswitch back to
position “0” to lock the controls.
4.2 To Disable/Enable all Sounders.
Note: Sounder disablement will be overridden by
Muster Alarm operation.
• To Access disable/enable mode:
o Turn the Access Controls Keyswitch on the
panel door to position “1”.
o Press the Select On/Off button to enter the
Select Mode.
o The Select On LED will light.
o The cursor indication will pulse the yellow
Zone 1 fault LED.
• To select the sounders:
Use the Select ↑ button to move the pulsed
cursor indication up through the fault LEDs
until it pulses the Sounder Fault/Disabled and
Sounder Test LEDs. [The Select ↓ button
moves the cursor down].
• To disable the sounders:
o Press the Disable button to disable the
sounders.
o The Sounder Fault/Disabled LED will
change to the “On-flash” indication while
the cursor is on it, changing to steady if the
cursor is moved.
o The general Disablement LED will light.
• To enable the sounders:
o Press the Enable button to enable the
sounders.
o The Sounder Fault/Disabled LED will
change to the “Off-flash” indication while
the cursor is on it, changing to off if the
cursor is moved on.
o The general Disablement LED will be
cleared if no other disablements are present.
• To quit the disable/enable mode:
o To exit the Select Mode, press the Select
On/Off button.
o The Select On LED will clear.
o The cursor indication will clear.
o Set the Access Controls Keyswitch back to
position “0” to lock the controls.
4.3 To Disable/Enable the Fire
Output.
• To Access disable/enable mode:
o Turn the Access Controls Keyswitch on the
panel door to position “1”.
o Press the Select On/Off button to enter the
Select Mode.
o The Select On LED will light.
