EQUIPMENT: T1200
PUBLICATION: 19A-4-O
ISSUE No. & DATE: 3 06/09
© 2006 Tyco Safety Products PAGE 9 of 13
Registered Company: Thorn Security Ltd. Registered Office: Dunhams Lane Letchworth Garden City Hertfordshire SG6 1BE
o The Fire Protection Fault/Disabled LED
will change to the “On-flash” indication
while the cursor is on it, changing to steady
if the cursor is moved.
o The general Disablement LED will light.
• To enable the Fire Protection Output:
o Press the Enable button to enable the Fire
Protection Output.
o The Fire Protection Fault/Disabled LED
will change to the “Off-flash” indication
while the cursor is on it, changing to off if
the cursor is moved on.
o The general Disablement LED will be
cleared if no other disablements are present.
• To quit the disable/enable mode:
o To exit the Select Mode, press the Select
On/Off button.
o The Select On LED will clear.
o The cursor indication will clear.
o Set the Access Controls Keyswitch back to
position “0” to lock the controls.
4.6 To Select/Clear One Man Zone
Test.
• To access test selection mode:
o Turn the Access Controls Keyswitch on the
panel door to position “1”.
o Press the Select On/Off button to enter the
Select Mode.
o The Select On LED will light.
o The cursor indication will pulse the yellow
Zone 1 fault LED.
• To select the zone to be tested:
Use the Select ↓ button to move the pulsed
cursor indication down through the fault LEDs
until it pulses on the required zone. [The Select
↑ button moves the cursor up].
• To apply the test mode to the selected zone:
o Press the Test button to activate the test
condition on the selected zone.
o The zone fault/disabled LED will change to
the “On-flash” indication while the cursor
is on it, changing to steady if the cursor is
moved on.
o The general Test LED will light.
• To clear the test mode on the selected zone:
o Press the Test button again or press the
Enable button to clear the test condition
enabling normal operation of the selected
zone.
o The zone fault/disabled LED will change to
the “Off-flash” indication while the cursor
is on it, changing to off if the cursor is
moved on.
o The general Test LED will be cleared if no
other circuits are in the test condition.
• To quit the zone test selection mode:
o To exit the Select Mode, press the Select
On/Off button.
o The Select On LED will clear.
o The cursor indication will clear.
o Set the Access Controls Keyswitch back to
position “0” to lock the controls.
4.7 To Select/Clear One Man Sounder
Test.
• To access test selection mode:
o Turn the Access Controls Keyswitch on the
panel door to position “1”.
o Press the Select On/Off button to enter the
Select Mode.
o The Select On LED will light.
o The cursor indication will pulse the yellow
Zone 1 fault LED.
• To select the sounders:
Use the Select ↑ button to move the pulsed
cursor indication up through the fault LEDs
until it pulses the Sounder Fault/Disabled and
Sounder Test LEDs. [The Select ↓ button
moves the cursor down].
• To activate the sounder test:
o Press the Test button to start the sounder
test.
o The Sounder Test LED will change to the
“On-flash” indication while the cursor is on
it, changing to steady if the cursor is
moved.
o The general Test LED will light.
o The sounders will operate for 2 seconds
every 15 seconds until the test mode is
switched off.
