TRACTOR CONTROLS
Steering wheel
Shuttle shift lever
Clutch pedal
PTO lever
4WD lever
Park brake lever
Main shift lever
Sub shift lever
Position lever
Tilt lever
Throttle lever
Brake pedal
Throttle pedal
Hydraulic control lever
36
►
►►
►Hand Throttle
Pulling the hand throttle towards the driver
increases revolutions.
Pushing it away from the driver decreases
revolution.
►
►►
►Clutch disconnecting arm
For long term storage of the Tractor it is
possible to latch the clutch in the disengaged
position.
Push the clutch down and engage the latch to
hold it there.
Do not attempt to start engine
when this arm is being used.
warning
