TYM T353 - OPERATING THE 3 POINT LINKAGE (TPL)

OPERATING THE 3 POINT LINKAGE (TPL)
Working Lamp
Hydraulic port
Trailer coupler
Top link
Always set the knob to lock when
1.Traveling on the road
2.Replacing tires or blades on an implement.
3.Making adjustments to an implement. Sudden dropping of an implement due
to hydraulic problems can cause serious injury or death.
Caution
42
Lift
rod(RH)
Lower link
Retention rubber
PTO shaft
Adjusting
handle
Check chain
Lift rod(LH)
