FILLING DIAGRAM & CAPACITY TABLE
No. Filling point Fillings Quantity Liter (gal.)
MODEL Allmand8435
1 RADIATOR Fresh clean Water(L.L.C) 7ℓ(1.85 US gal)
2 ENGINE API : CF-4 grades
Above:25°C(77°F)…SAE30 or 15W/40
0°C to 25°C(32°F to 77°F)…SAE20 or
10W30
Below 0°C(32°F)…SAE 10W or 10W-30
5 ℓ (1.32 US gal)
3 TRANSMISSION CASE See next page * 36ℓ(9.52 US gal)
4 FRONT AXLE Gear oil #80 or #90 (API GL-4 grade) 8.2ℓ(2.166US gal)
5 FINAL DRIVE CASE(B) Gear oil #80 or #90 (API GL-4 grade)
6 Clutch pedal shaft Grease As required
7 BALL JOINT Grease As required
8 FUEL TANK Diesel fuel 33ℓ(8.717 US gal)
58
