u-blox XPLR-AOA-3 User Manual

XPLR-AOA-3 - User guide
UBX-22006906 - R07 EVB-ANT-1 Page 22 of 46
C1-Public
Figure 21: EVB-ANT-1 mechanical dimensions
4.9 Notes
4.9.1 Hardware and software revisions
The hardware revisions available for EVB-ANT-1 are shown in Table 4.
Hardware revision
Notes
B
Initial revision
C
Offers improved ethernet stability compared to revision B
Table 4 EVB-ANT-1 hardware revisions
The revisions of EVB-ANT-1 example software now available on GitHub [19] are shown in Table 5.
Software revision
Notes
Compatibility
0.1
Initial version published
Hardware revision B only
1.0
General updates
Compatible with hardware revisions B and C
Table 5 EVB-ANT-1 example software revisions
4.9.2 Limitations and known issues
The issues described in this section relate to both the EVB-ANT-1 hardware and the example software
from GitHub [19].
• The ethernet functionality works best if the ethernet cable is plugged to the board before startup.
• To implement changes in the configuration, EVB-ANT-1 must be rebooted.
• The configuration web page doesn’t use secure communication
• The Wi-Fi pass phrase is stored internally in the module in plain text and not encrypted
