1 = Basic pcb
Basic pcb
2 = Mulple switch (opon) X15 = external Bus/ModBus
3 = Humidity sensor (opon) X16 = 24V
4 = USB connector x17 = eBus
5 = USB sck for updang soware (not supplied with appliance) X18 = 24V (max 5VA)
6 = Service connector X19 = Signal output
7 = Laptop with installed service tool (not supplied)
8 = Touchscreen on appliance
Plus pcb
9 = Valve motor bypass valve X03 = 24V
10 = Air temperature sensor X04 = external Bus
11 = Exhaust fan* X06 = ModBus
12 = Internal preheater incl. maximum security X08 = Contact input 1
13 = Supply fan* X09 = Contact input 2
14 = Power supply 230V 50Hz X10 = Relais output 1
15 = Air Control (opon) X11 = Relais output 2
16 = CO
2
sensor eBus (opon) X12 = Analog input (0 to 10 V)
17 = Heater eBus (opon) X13 = Analog input (0 to 10 V)
18 Zone valve demand-driven venlaon 2.0 (opon) X14 = Analog output (0 or 10 V)
19 = Plus pcb (opon) X15 = Analog output 2 (0 or 10 V)
20 = Connecon on ModBus system (opon) X16 = NTC 10K
21 =
X12 is Jumper terminang resistance (120 W) ModBus (remove if
terminang resistance has already been placed in ModBus system).
With Modbus applicaon remove the jumpers X121 & X122; when
using external Bus place the jumpers X12, X121 & X122; remove
Jumper X07 from Plus pcb when a Plus pcb is applied.
X17 = LAN
Wire colours
* The control cables of the fans can be switched with no problem;
when the power is switched on the appliance determines itself
which is the supply and exhaust fan!
When the appliance detects another fan (for example when a fan is
replaced during service acvies), then a “wizard” starts up
automacally; follow the instrucons on the display for the correct
connecon of the fan cables.
C1
C2
C3
C5
C8
C10
C11
C17
=
=
=
=
=
=
=
=
brown
blue
green/yellow
white
grey
yellow
green
purple
Ubiflux Vigor W325 615743-G
