ZED-F9R-Integration manual
Message type Description
RTCM 1005 Stationary RTK reference station ARP
RTCM 1006 Stationary RTK reference station ARP with antenna height
RTCM 1007 Antenna descriptor
RTCM 1009 L1-only GLONASS RTK observables
RTCM 1010 Extended L1-only GLONASS RTK observables
RTCM 1011 L1/L2 GLONASS RTK observables
RTCM 1012 Extended L1/L2 GLONASS RTK observables
RTCM 1033 Receiver and Antenna Description
RTCM 1074 GPS MSM4
RTCM 1075 GPS MSM5
RTCM 1077 GPS MSM7
RTCM 1084 GLONASS MSM4
RTCM 1085 GLONASS MSM5
RTCM 1087 GLONASS MSM7
RTCM 1094 Galileo MSM4
RTCM 1095 Galileo MSM5
RTCM 1097 Galileo MSM7
RTCM 1124 BeiDou MSM4
RTCM 1125 BeiDou MSM5
RTCM 1127 BeiDou MSM7
RTCM 1230 GLONASS code-phase biases
Table 4: ZED-F9R supported input RTCM version 3.3 messages
3.1.5.2 NTRIP - networked transport of RTCM via internet protocol
Networked Transport of RTCM via internet protocol, or NTRIP, is an open standard protocol for
streaming differential data and other kinds of GNSS streaming data over the internet in accordance
with specifications published by RTCM.
The NTRIP protocol is also used by SSR correction service providers to stream SSR correction data
over the internet (e.g. SPARTN corrections).
There are three major parts to the NTRIP system: The NTRIP client, the NTRIP server, and the NTRIP
caster:
1. The NTRIP server is a PC or an on-board computer running NTRIP server software
communicating directly with a GNSS reference station. The NTRIP server serves as the
intermediary between the GNSS receiver (NTRIP Source) streaming correction data and the
NTRIP caster.
2. The NTRIP caster is an HTTP server which receives streaming correction data from one or
more NTRIP servers and in turn streams the correction data to one or more NTRIP clients via
the internet.
3. The NTRIP client receives streaming correction data from the NTRIP caster to apply as real-
time corrections to a GNSS receiver.
u-center GNSS evaluation software provides an NTRIP client application that can help to evaluate a
ZED-F9R design. The u-center NTRIP client connects over the internet to an NTRIP service provider,
using access credentials such as user name and password from the service provider. The u-center
NTRIP client then forwards the RTCM 3.3 corrections to a ZED-F9R receiver connected to the local
UBX-20039643 - R06
3 Receiver functionality Page 14 of 119
C1-Public
