UNI-T UT207 User Manual

Table of Contents
Title Page
Overview
Unpacking Inspection
Safety Information
Rules For Safe Operation
International Electrical Symbols
The Meter Structure
Functional Buttons
The Effectiveness of Functional Buttons
Display Symbols
Measurement Operation
A. DC/AC Voltage Measurement
B. Measuring Resistance
C. Testing Diodes
D. Testing for Continuity
E. Frequency Measurement
F. Duty Cycle Measurement
4
5
6
7
10
11
12
14
15
18
18
20
22
24
26
28
Model UT207/208: OPERATING MANUAL
1

UNI-T UT207 Specifications

General

Backlight	Yes
AC current range	66 - 1000 A
DC voltage range	6.6 - 600 V
Resistance range	20 - 20000 Ω
Basic accuracy (frequency)	±(0.1%+3)
Basic accuracy (DC current)	±(1.5%+8)
Basic accuracy (DC voltage)	±(0.8%+1)
Basic accuracy (resistance)	±(1%+2)
Temperature measurement range	-40 - 1000 °C
Dimensions (WxDxH)	105 x 45 x 286 mm
Battery voltage	9 V

Weight and Dimensions

Weight	533 g
