UNI-T UT207 User Manual

B. Replacing the Battery (see figure 12)
Figure 12
To avoid false readings, which could lead
to possible electric shock or personal
injury, replace the battery as soon as the
battery indicator “ ” appears.
Make sure the transformer jaw and the
tets leads are disconected from the circuit
being tested before opening the case
bottom.
Warning
Model UT207/208: OPERATING MANUAL
50

UNI-T UT207 Specifications

General

Backlight	Yes
AC current range	66 - 1000 A
DC voltage range	6.6 - 600 V
Resistance range	20 - 20000 Ω
Basic accuracy (frequency)	±(0.1%+3)
Basic accuracy (DC current)	±(1.5%+8)
Basic accuracy (DC voltage)	±(0.8%+1)
Basic accuracy (resistance)	±(1%+2)
Temperature measurement range	-40 - 1000 °C
Dimensions (WxDxH)	105 x 45 x 286 mm
Battery voltage	9 V

Weight and Dimensions

Weight	533 g
