UNI-T UT207 User Manual

To replace the battery:
1. Turn the Meter off and remove all the connections from the input terminals
2. Turn the Meter’s front case down.
3. Remove the screw from the battery compartment, and separate the battery
compartment from the case bottom.
4. Take out the old battery and replace with a new 9V battery (6LF22, 1604A).
5. Rejoin the case bottom and the battery compartment, and reinstall the screw.
Model UT207/208: OPERATING MANUAL
51

UNI-T UT207 Specifications

General

Backlight	Yes
AC current range	66 - 1000 A
DC voltage range	6.6 - 600 V
Resistance range	20 - 20000 Ω
Basic accuracy (frequency)	±(0.1%+3)
Basic accuracy (DC current)	±(1.5%+8)
Basic accuracy (DC voltage)	±(0.8%+1)
Basic accuracy (resistance)	±(1%+2)
Temperature measurement range	-40 - 1000 °C
Dimensions (WxDxH)	105 x 45 x 286 mm
Battery voltage	9 V

Weight and Dimensions

Weight	533 g
