F. Frequency

Range

660.0Hz

6.600kHz

66.00kHz

660.0kHz

6.600MHz

66.00MHz

Resolution

0.1Hz

0.001kHz

0.01kHz

0.1kHz

0.001MHz

0.01MHz

Accuracy

(0.1%+3)

Overload protection

250VAC

Remarks:

Input Sensitivity (a) as follows:

When a 10Hz: the Meter does not response

When 10Hz < a 100kHz: 300mV rms

When a >100kHz: 600mV rms

Model UT207/208: OPERATING MANUAL

Questions and Answers:

Need help?

Do you have a question about the UNI-T UT207 and is the answer not in the manual?

General

Backlight	Yes
AC current range	66 - 1000 A
DC voltage range	6.6 - 600 V
Resistance range	20 - 20000 Ω
Basic accuracy (frequency)	±(0.1%+3)
Basic accuracy (DC current)	±(1.5%+8)
Basic accuracy (DC voltage)	±(0.8%+1)
Basic accuracy (resistance)	±(1%+2)
Temperature measurement range	-40 - 1000 °C
Dimensions (WxDxH)	105 x 45 x 286 mm
Battery voltage	9 V
