Output
Accuracy of
Voltage
±(1.0% Setting +5V) (no load)
±(1.0% Setting +5V)
(no load)
Test
Accuracy of
Voltage
±(1.0% Reading +5V)
±(1.0% Reading +5V)
Producing
Mode of
Voltage
DDS signal source plus AB power
amplifier
DDS signal source
plus AB power
amplifier
Current
Test Range
AC
Current
Range
0.001mA – 10mA
0.001mA – 20mA
Short-
circuit
Current
>20 mA
>40 mA
(Transient）
(output voltage setting >500V)
(output voltage
setting >500V)
Resoultion
of Current
0.001 mA
0.001 mA
Accuracy of
Current
±(2.0% Reading + 5 characters)
±(2.0% Reading + 5
characters)
Actucal
Current
OFF, 0.001 mA-10mA
OFF, 0.001 mA-20mA
DC
Current
Range
0.1uA – 5.00mA
0.1uA – 10.00mA
Accuracy of
Current
±(2.0% Reading + 5 characters)
±(2.0% Reading + 5
characters)
Discharge
Automaically discharge after the
test is finished
Automaically
discharge after the
test is finished
Insulation Resistance Test
Output Voltage
0.050kV–2.500kV
(optional 5.00kV）
0.050kV–
2.500kV(optional
5.00kV）
Rsoulation of Voltage
1V
1V
Test Accuracy of Voltage
±(1.0% Reading +2V)
±(1.0% Reading +2V)
Maximum Output Current
5mA
10mA
Maximum Output Power
12.5VA (2500V/5mA)
25VA (2500V/10mA)
Output Transient Short-circuit
Current
>10mA (output voltage
setting >500V)
>20mA(output voltage
setting >500V)
