UNI-T UT71A User Manual

Model UT71A/B/C/D/E: OPERATING MANUAL
Table 2-2. Functional Buttons
Button Description Access Method
Press the button once.
Press and hold the button for over 1
second.
Press the button once.
Press and hold
the button for over 1 second.
Press the button once after entering
SEND mode.
Press to exit certain button functions and the Meter will return
to the factory default setting.
Press to turn the backlight on. It is possible to toggle between
1
st
and the 2
nd
backlight level and Exit the feature by pressing
this button. After exiting the light feature, it is necessary to press
and hold the button for over 1 second to turn the backlight on
again.
Press to display max, min and average values.
Press EXIT to stop and return to current measurement mode.
Press to output the data, AUTO mode switch off. The primary
display shows "SEND".
Press EXIT to exit.
In Setup, each press to decrement an Option.
In Recall, each press to go back to the previous stored reading.
EXIT
LIGHT
MAXMIN
SEND
18

UNI-T UT71A Specifications

General

Data hold	Yes
Product type	Digital multimeter
Frequency range	0.02 - 200000 kHz
AC current range	0.2 - 10 A
AC voltage range	2 - 1000 V
DC voltage range	0.2 - 1000 V
Capacitance range	20 - 20000 nF
Statistic function	Maximum, Minimum
Basic accuracy (frequency)	0.1%+15
Basic accuracy (DC current)	0.2%+20
Basic accuracy (DC voltage)	0.1%+8
Basic accuracy (resistance)	0.5%+20
Basic accuracy (capacitance)	1.5%+20
Dimensions (WxDxH)	93 x 40 x 200 mm
Battery voltage	9 V

Weight and Dimensions

Weight	384 g
