Model UT71A/B/C/D/E: OPERATING MANUAL
Feature Summary
Tri Digital Displays
Analogue Bar Graph
Backlight with 2 brightness levels
Autorange
AC+DC True RMS, AC RMS
Data Hold
Continuity
Bar Graph
Duty Cycle
MAX MIN Mode
Battery Access Door
Primary: 40,000 counts
Left Secondary: 4000 counts
Right Secondary: 4000 counts
Bar Graph: 40 segments, updates 10 times / second
Bright backlight for clear readings in poorly lighted areas.
The Meter automatically selects best range
Choices for AC only or AC+DC readings
Holds readings on display
Beeper sounds for resistance readings below threshold.
40 segments
Measure signal on or off time in %.
Record maximum and minimum
Battery replaceable.

UNI-T UT71A Specifications

General

Data hold	Yes
Product type	Digital multimeter
Frequency range	0.02 - 200000 kHz
AC current range	0.2 - 10 A
AC voltage range	2 - 1000 V
DC voltage range	0.2 - 1000 V
Capacitance range	20 - 20000 nF
Statistic function	Maximum, Minimum
Basic accuracy (frequency)	0.1%+15
Basic accuracy (DC current)	0.2%+20
Basic accuracy (DC voltage)	0.1%+8
Basic accuracy (resistance)	0.5%+20
Basic accuracy (capacitance)	1.5%+20
Dimensions (WxDxH)	93 x 40 x 200 mm
Battery voltage	9 V

Weight and Dimensions

Weight	384 g
