Model UT71A/B/C/D/E: OPERATING MANUAL
Chapter 7
Specifications
Safety and Compliances
Maximum Voltage between any Terminal and Grounding
Certification
Compliances
Fused Protection for µAmA input terminal:
Fused Protection for A input terminal:
Refer to different range input protection voltage
IEC 61010 CAT.III 1000V, CAT.IV 600V overvoltage and
double insulation standard
0.5A, 1000V, fast type fuse, 6.3x32mm
10A , 1000V,fast type fuse, 10.3x38mm

UNI-T UT71A Specifications

General

Data hold	Yes
Product type	Digital multimeter
Frequency range	0.02 - 200000 kHz
AC current range	0.2 - 10 A
AC voltage range	2 - 1000 V
DC voltage range	0.2 - 1000 V
Capacitance range	20 - 20000 nF
Statistic function	Maximum, Minimum
Basic accuracy (frequency)	0.1%+15
Basic accuracy (DC current)	0.2%+20
Basic accuracy (DC voltage)	0.1%+8
Basic accuracy (resistance)	0.5%+20
Basic accuracy (capacitance)	1.5%+20
Dimensions (WxDxH)	93 x 40 x 200 mm
Battery voltage	9 V

Weight and Dimensions

Weight	384 g
