Model UT71A/B/C/D/E: OPERATING MANUAL
Chapter 5
Changing the Default Setting
Introduction
The Meter allows you to change the default operating configuration of the Meter by changing setup options made
at the factory.
These settings are stored and can be changed in the Setup mode using the procedure described in this chapter.
Selecting Setup Options
To enter the Setup mode, turn the Meter on and press and hold SETUP button for over 1 second. It is recommended
to change the default setting only when the Meter is at DCV measurement mode.
In the Setup mode, each press of SETUP button steps to the next Selection. Each press of - or + button decrement
or increment an Option.
Each Setup Selection and Option appears in the primary display in the sequence shown in Table 5-1.

UNI-T UT71A Specifications

General

Data hold	Yes
Product type	Digital multimeter
Frequency range	0.02 - 200000 kHz
AC current range	0.2 - 10 A
AC voltage range	2 - 1000 V
DC voltage range	0.2 - 1000 V
Capacitance range	20 - 20000 nF
Statistic function	Maximum, Minimum
Basic accuracy (frequency)	0.1%+15
Basic accuracy (DC current)	0.2%+20
Basic accuracy (DC voltage)	0.1%+8
Basic accuracy (resistance)	0.5%+20
Basic accuracy (capacitance)	1.5%+20
Dimensions (WxDxH)	93 x 40 x 200 mm
Battery voltage	9 V

Weight and Dimensions

Weight	384 g
