UNI-T UT71A User Manual

36
Model UT71A/B/C/D/E: OPERATING MANUAL
Figure 3-4. Continuity Test
Note
Open circuit voltage around -1.2V and range is 400
measurement range.
When continuity testing has been completed,
disconnect the connection between the testing leads
and the circuit under test and remove the test leads
away from the input terminals.
l
l

UNI-T UT71A Specifications

General

Data hold	Yes
Product type	Digital multimeter
Frequency range	0.02 - 200000 kHz
AC current range	0.2 - 10 A
AC voltage range	2 - 1000 V
DC voltage range	0.2 - 1000 V
Capacitance range	20 - 20000 nF
Statistic function	Maximum, Minimum
Basic accuracy (frequency)	0.1%+15
Basic accuracy (DC current)	0.2%+20
Basic accuracy (DC voltage)	0.1%+8
Basic accuracy (resistance)	0.5%+20
Basic accuracy (capacitance)	1.5%+20
Dimensions (WxDxH)	93 x 40 x 200 mm
Battery voltage	9 V

Weight and Dimensions

Weight	384 g
