UNI-T UTG1000X Series User Manual

User’s Manual UTG1000X Series
Instruments.uni-trend.com 34 / 74
is sine wave).
Press Freq soft key to set the frequency, use numerical keyboard to input 900 and then select the unit of
parameter to Hz;
Press Amp soft key to set the amplitude, use numerical keyboard to input 100 and then select the unit of
parameter to mVpp. As shown in the following figure.
4) Set Phase Deviation
After the parameter setting of the carrier wave is completed, press ModeShape PM to enter PM mode
setting,
Press PhaseDev soft key and use numerical keyboard to input 200 and then select the unit of parameter
to ° .

UNI-T UTG1000X Series Specifications

General

Brand	UNI-T
Model	UTG1000X Series
Category	Portable Generator
Language	English
