User’s Manual UTG1000X Series
Instruments.uni-trend.com 36 / 74
different modulation mode for the two channels.
Select ASK
Press Mode ShapeASK to turn on ASK mode, the waveform generator will output the modulated
waveform according to the currently ASK rate and the carrier wave.
Select Carrier Wave
The carrier wave can be sine wave, square wave, ramp wave or arbitrary wave (except DC). The default is sine
wave. After ASK mode is selected, press Wave key to enter the carrier wave interface.
Set Frequency for Carrier Wave
Refer to Set Frequency for Carrier Wave in AM mode.
Set Modulation Source
The modulation source of this instrument can be select internal or external. When ASK mode is enabled, the
default modulation source is internal; It can be change by multifunction rotary knob or press ModSrc
External soft key.
