UNI-T UTL8500 Series User Manual

UTL8500 Series User Manual
12
2.1 Packing List
Before using the instrument, please first:
1. Check whether the appearance of the product is damaged, scratched or has other
defects;
2. Check whether the instrument accessories are missing according to the instrument
packing list.
If it is damaged or the accessories are missing, please contact Uni-Trend Instrument Sales
Department or the distributor immediately.
Items
Quantity
Remarks
Programmable DC
Electronic Load
1pc
The model is subject to the
actual order.
Power Cable
1pc
Standard Cable 250V/10A for
China
Spare Fuse
2pcs
240V/0.25A, Suitable for 10V
Voltage
User Manual
1pc
Users can download the
manuals from UNI-T’s official
website.
Factory Quality
Report
1pc
For UTL8512B+ and UTL8513
Certificate of
Conformity and
Warranty
1pc
2.2 Requirements of Power Supply
UTL8500 series can only be used in following conditions:
Parameters
Requirements
Voltage
AC 220/110 (±10%)V
Frequency
50/60Hz
Power
50W
Fuse
AC220V Input Voltage: 240V/0.25A
AC110V Input Voltage: 120V/0.5A
 Three-core power cable is provided; please make sure that the ground wire of three-
phase socket is properly grounded before use.
 The instrument comes with 220V/110V power transfer switch. Before connecting to
