SERVICE DATA
5-5
Engine cylinder head bolt torque
The engine cylinder head bolts are tightened by the angle
tightening method and thus they do not need to be retightened.
When replacing the cylinder head gaskets with new ones, be sure
to tighten the cylinder head bolts in the following manner:
1) Apply molybdenum disulde grease on the head bolt threads
and seat surface.
2) Tighten the cylinder head bolts from center to outside evenly
in the three steps:
1st step: Tighten to 69 N-m (7 kgf-m) and back off.
2nd step: Tighten to 88 N-m (9 kgf-m).
3rd step: Turn further 90 to 120 degrees.
NOTE
The cylinder head bolts must not be reused more than 5 times.
They must be replaced with new ones after 5 times of removal
or earlier.
Engine specications
Idling rpm 800 - 850
Non-load max. rpm 2450 - 2550
Fuel injection order 1 - 5 - 3 - 6 - 2 - 4
Fuel injection timing BTDC 12°
Fuel injection start pressure 18.1 MPa (185 kgf/cm
2
)
Compression pressure 3.2 MPa (31 kgf/cm
2
)/200 rpm
Valve clearance mm
(both intake and exhaust)
0.40 (in cold)
Deection of lift chains
No difference in deection is allowed when both chains are pressed
midway on the span with the same pressure.
Steering wheel play
60 - 70 mm
BOLT AND NUT TORQUE
Tightening torque of major bolts and nuts
FD160-2 - 230-2
N-m (kgf-m)
Engine mount nut
Engine side 66.6 (6.8)
Frame side 50 (5.1)
Transmission mount nut
Frame side 510 (52)
Transmission side 203 (20.7)
Front axle mount bolt 2390 (243)
Rear axle support bolt 782 (80)
Mast support cap bolt 1830 (186)
Wheel lug nut
Front 686 (70)
Rear 441 - 490 (45 - 50)
Propeller shaft joint bolt 104 (10)
