PICTORIAL NOMENCLATURE
2-1
FORKS
LIFT CHAIN
SIDEVIEW
MIRROR
FRONT WHEEL
(DRIVE WHEEL)
REAR WHEEL
Note: The operator’s cab (with head lights, wiper, air conditioner), high-lift mast, and side shifter are optionally available.
REAR UNDER-
MIRROR
MUFFLER
OPERATOR’S CAB
MAST
BATTERY BOX
HEAD LAMP
LIFT CYLINDER
AIR
CLEANER
HYDRAULIC
OIL TANK
HOOD
