INSTRUMENTS AND CONTROLSINSTRUMENTS AND CONTROLS
2-172-17
FOOT SWITCH [3]FOOT SWITCH [3]
WARNINGWARNING
Keep the foot switch depressed with your leftKeep the foot switch depressed with your left
foot during operation. The foot switch is afoot during operation. The foot switch is a
safety device that helps keep your left leg insafety device that helps keep your left leg in
the operator’s compartment. Operation of thethe operator’s compartment. Operation of the
truck in confined spaces with your leg outsidetruck in confined spaces with your leg outside
the operator’s compartment might cause it to bethe operator’s compartment might cause it to be
crushed between the truck and a building wall orcrushed between the truck and a building wall or
post, resulting in a broken leg.post, resulting in a broken leg.
If the foot switch is released during operation, theIf the foot switch is released during operation, the
brake is applied and the traveling circuit shuts offbrake is applied and the traveling circuit shuts off
automatically.automatically.
BATTERY LOCK RELEASE PEDAL [1]BATTERY LOCK RELEASE PEDAL [1]
This pedal is used to remove and return the batteryThis pedal is used to remove and return the battery
pack.pack.
Step on the pedal and hold it down while pressing theStep on the pedal and hold it down while pressing the
reach lever to advance the mast. Then remove or returnreach lever to advance the mast. Then remove or return
the battery pack.the battery pack.
11
33
