INSTRUMENTS AND CONTROLSINSTRUMENTS AND CONTROLS
2-212-21
ARM GUARD [1]ARM GUARD [1]
WARNINGWARNING
The arm guard is a safety device that protects theThe arm guard is a safety device that protects the
operator from injury.operator from injury.
Do not remove it. A damaged arm guard shouldDo not remove it. A damaged arm guard should
be replaced with a new one.be replaced with a new one.
The arm guard helps prevent the operator from reachingThe arm guard helps prevent the operator from reaching
into the mast and getting his arm caught or accidentallyinto the mast and getting his arm caught or accidentally
cut off.cut off.
HYDRAULIC OIL TANK CAP [2]HYDRAULIC OIL TANK CAP [2]
The hydraulic oil tank cap is located under theThe hydraulic oil tank cap is located under the
oorboard.oorboard.
Remove the cap and pour hydraulic oil through the llRemove the cap and pour hydraulic oil through the ll
port.port.
The tank cap is tted with an oil dipstick.The tank cap is tted with an oil dipstick.
BATTERBATTERY ELECTRY ELECTROLOLYTE YTE LEVEL INLEVEL INDICATORDICATOR
(OPTION) [3](OPTION) [3]
The battery electrolyte level indicator is on the batteryThe battery electrolyte level indicator is on the battery
case, so you can check the electrolyte level in thecase, so you can check the electrolyte level in the
battery without pulling out the battery.battery without pulling out the battery.
The green lamp stays on, and indicates that the levelThe green lamp stays on, and indicates that the level
indicator sensor is operating.indicator sensor is operating.
The red lamp comes on when the electrolyte level getsThe red lamp comes on when the electrolyte level gets
close to the lower limit. If the red lamp is blinks, addclose to the lower limit. If the red lamp is blinks, add
distilled water as soon as possible.distilled water as soon as possible.
Check the electrolyte levels in all the Check the electrolyte levels in all the cells periodicallycells periodically..
11
22
33
