27
ITEM PURPOSE
LCD The Liquid Crystal Display (LCD) shows the
current channel or its frequency. It also
displays mode, status, and bank indicators.
It utilizes a 7-segment LCD pattern for
character display. (Go to “Screens” on page
36 for more details.)
BC355C REAR PANEL
ITEM PURPOSE
ANT BNC Antenna Connector. Insert the antenna
plug here.
