Mounting the Base Unit on
a Wall
Mounting the Base Unit on a Wall [10]
www.uniden.com
Mounting the Base Unit on a Wall
Standard wall plate mounting
This phone can be mounted on any standard wall plate.
1) Plug the AC adapter into the DC IN 9V jack.
2) Plug the telephone line cord into the TEL
LINE jack. Wrap the cord inside the molded
wiring channel as shown.
3) Snap the wall mount adapter into the
notches on the base top.
4) Wrap the AC adapter cord and telephone
line cord inside the molded wiring channel
as shown.
5) Plug the AC adapter into a standard 120V
AC wall outlet.
6) Plug the telephone line cord into the
telephone outlet.
7) Align the mounting slots on the base with
the mounting posts on the wall. Then push
in and down until the phone is firmly
seated.
DO NOT use an AC
outlet controlled by a
wall switch.
!
