Installation and Configuration
Installation Procedure
Installation and Configuration
The Wireless Service Gateway WSG can be mounted vertically on a wall or be placed horizon-
tally in a 19" rack. It must be fixed by screws or other fixtures to the wall or rack, and must not be
easily movable.
Installation Procedure
1) Mount the device, see Mounting on page 14 below.
2) Connect the supply voltage, see Supply Voltage on page 19.
3) Access the module via the web interface, see Accessing Wireless Service Gateway WSG on
page 22.
4) Fill in all required data, see Basic Configuration on page 27.
5) Connect to required equipment, such as Ascom systems, other external equipment, etc. see
Connections on page 21.
Mounting
Wireless Service Gateway WSG should be placed in a dry environment with a temperature
range of 0 to +40ºC.
Wall Mounting
Four screws size 3,5×40 together with four wall plugs and four screws size M3×6, are deli-
vered with the product. The M3×6 screws are used for attaching the assembly brackets to
the module. Use the 3,5×40 screws for walls made of wood. For walls made of concrete and
bricks use them together with the wall plugs. For other types of walls use suitable screws
and plugs according to wall material.
When mounted on a wall, it is of great importance that the connections are located in a ver-
tical plane to fulfil the fire classification.
1) Fasten the supplied assembly brackets on the bottom side of the module.
2) Use the supplied screws and wall plugs (or other suitable screws and plugs dependent on
wall material) and mount the module as shown in the picture below
A31003-M2000-J109-01-7631, 30/06/2020
14 Wireless Service Gateway WSG, Installation Guide
