• Prot
Pro
Protection code
Prot Display Modification
0 SP, Hy.P, Hy.n, AL.2, AL.3, PoS, OuP, INF SP, Hy.P , Hy.n, AL.2, AL.3, PoS
1 SP, Hy.P, Hy.n, AL.2, AL.3, PoS, OuP, INF SP
2 SP, OuP, INF
+ 4 to disable InP, Out
+ 8 to disable CFG
+ 16 to disable SW “power-up - power down”
+ 32 disable manual power latching
+ 64 to disable manual power modification
+128 enables full configuration
Note: OuP and INF only display configuration extended
12
(tr
hd.1
• Hrd
Hrd
Hardware configuration
Enable multiset instrument control by
serial
Control type
Val Control type
0 P heat
1
2
3 PI heat
4
5
6 PID heat
7
8
9 ON-OFF heat
10
11
12
13
14
Selection of derivative action sampling time:
+ 0 sample 1 sec.
+ 16 sample 4 sec.
+ 32 sample 8 sec.
+ 64 sample 240 msec.
Note: LbA alarm is not enabled with ON/
OFF type control
0
6
al.n
bvt.
AL.nr Alarme1 Alarm 2 Alarm 3
1 enabled disabled disabled
Select number of enabled
alarms
0 No function (key disenabled))
1 MAN / AUTO controller
2
3 HOLD
4
5
6 Start/Stop selftuning
7 Start/Stop autotuning
8
b u t t
Function of M/A keys
+ 16 disables the “back menu” function (Auto/Man + F keys) in
the configuration menus
dsp
Defining SV display
function
diSP Lower display (SV) function
0 SSP - setpoint enabled
1 PoS - valve position
2 Control output value
3 Deviation (SSP - PV)
1
1
0
780379_MHW_600V-T73_06-2012_ENG
