ld.1
ld.2
ld.3
Function of LEDs
+ 16 LED flashes if active
Val. Function
0 none
1 MAN/AUTO controller
2
3 HOLD
4 Selftuning enabled
5 Autotuning enabled
6
7
8 Error present
9 Softstart running
10
11 Set point gradient running
12 Pre-heating running
1
28
20
Step 34 mV full scale
s.34
Step 33
mV beginning scale
s.33
......
s.00
• Lin
Lin
Custom linearization for main input
the n step value corresponds to input:
mV beginning scale + n*∆mV
∆mV = (mV full scale - mV beginning scale) / 32
Step 0 beginning
of scale value
Step 32
full of scale value
Display limits
(-1999…9999)
Display limits
(-1999…9999)
s.32
Step 35
mV at 50°C
s.35
Only for TYP = Tc custom
• U.CAL
U.CA
User
calibration
Val Function
1 -
2 Input 1 – custom 10V / 20mA
3 Input 1 - custom 60mV
4 Custom PT100 / J PT100
5 Custom PTC
6 Custom NTC
7 -
