TABLE 2 - INPUTS CONFIGURATION C111
Red display
Analog input 1 1^ digit 2^ digit 3^ digit 4^ digit
Pt100 3 wires
0
Pt100 22 wires
1
Ni100 3 wires
2
Ni100 22 wires
3
Pt1000 3 wires
4
Pt 1000 22 wires
5
Ni1000 3 wires DIN 43760
6
Ni1000 22 wires DIN 43760
7
Ni1000 3 wires Siemens
8
Ni1000 22 wires Siemens
9
Thermocoupling K NiCr-Ni
A
Thermocoupling T Cu-Con
b
Thermocoupling N NiCrSil-NiSil
C
Thermocoupling J Fe-Con
d
Signal 0 ÷ 20 mA
E
Signal 4 ÷ 20 mA
F
Signal 0 ÷ 10 V
G
Signal 0 ÷ 1 V
H
Analog input 2
none
0
external set point WFG
1
external set point 0 ÷ 20 mA
2
external set point 4 ÷ 20 mA
3
external set point 0 ÷ 10 V
4
external set point 0 ÷ 1 V
5
analog shift set-point WFG
6
analog shift set-point 0 ÷ 20 mA
7
analog shift set-point 4 ÷ 20 mA
8
analog shift set-point 0 ÷ 10 V
9
analog shift set-point 0 ÷ 1 V
A
Analog input 3
none
0
external themperature sensor Pt 1000 22 wires
1
xternal themperature sensor Ni1000 22 wires DIN
2
xternal themperature sensor Ni1000 22 wires Siemens
3
Input D2 - Logic functions
none
0
changeover set-point
1
V shift set-point
2
Typical settings
Siemens sensors QAE2../QAC2../QAM2..
9030
Factory sensors Pt1000 30÷130 °C
5030
Factory sensors Pt1000 0 ÷ 350 °C
5030
Pressure probes QBE... 3 wires (signal 0 ÷ 10 V)
G030
Pressure probes MBS... 2 wires (signal 4 ÷ 20 mA)
F030
Probes Pt100 3 wires
0030
Thermocouplings K type
A030
Signal 4 ÷ 20 mA
F030
