7
TABLE 3 - CONFIGURATION C112
Note: (*) for RWF 40.002 only
Red display 1^ digit 2^ digit 3^ digit 4^ digit
Auxiliary limit switch K6
none 0
lk1 function for input 1
1
lk2 function for input 1
2
lk3 function for input 1
3
lk4 function for input 1
4
lk5 function for input 1
5
lk6 function for input1
6
lk7 function for input 1
7
lk8 function for input 2
8
lk7 function for input 2
9
lk8 function for input 2
A
lk7 function for input 3
b
lk8 function for input 3
C
Type of instrumentoutput control
3 points (relay type)
0
DC 0 ÷ 20 mA (*)
1
DC 4 ÷ 20 mA (*)
2
DC 0 ÷ 10 V (*)
3
Set-point SP1
SP1set with keys
0
SP1 dependent on outside sensor (analogue input 3
must be configured)
1
Parameter lock
no keyboard lock
0
configuration level block
1
parameters level block PID
2
total block
3
Factory settings 0 0 1 0
