Probe parameters configuration MODULATORE ASCON KM3
Parameter Group inP AL1 rEG SP Parameter Sens dp SSC FSc unit IO4.F AL1 HAL1 Pb ti td Str.t db.S SPLL SPHL SP
(**) (***) (***) (***) (***) (***) (***)
Probes Dec Scale Scale Off On p i d servo Band SP SP Set
Point Min Max time s Mo. Min Max point
Pt1000 (130°C max) Pt10 1 °C on 5 10 10 350 1 * 5 30 95 80
Pt1000 ( 350°C max) PT10 1 °C on 10 10 10 350 1 * 5 0 350 80
Pt100 (130°C max) PT1 1 °C on 5 10 10 350 1 * 5 0 95 80 Pt100 (350°C max) Pt1 1 °C on 10 10 10 350 1 * 5 0 350 80
Pt100 (0÷100°C 4÷20mA) 4.20 1 0 100 on 5 10 10 350 1 * 5 0 95 80
Thermocouple K (1200°C max) crAL 0 °C on 20 25 10 350 1 * 5 0 1200 80
Thermocouple J (1000°C max) J 0 °C on 20 25 10 350 1 * 5 0 1000 80
4-20mA / 0-1,6barPressure probe 4.20 0 0 160 on 20 20 5 120 1 * 5 0 160 100
4-20mA / 0-10bar Pressure probe 4.20 0 0 1000 on 50 50 5 120 1 * 5 0 1000 600
4-20mA / 0-16bar Pressure probe 4.20 0 0 1600 on 80
80 5 120 1 * 5 0 1600 600
4-20mA / 0-25bar Pressure probe 4.20 0 0 2500 on 125 125 5 120 1 * 5 0 2500 600
4-20mA / 0-40bar Pressure probe 4.20 0 0 4000 on 200 200 5 120 1 * 5 0 4000 600
QBE2002 / 0-25bar Pressure probe 0.10 0 0 2500 0n 125 125 5 120 1 * 5 0 2500 600
Note:
(*) Str.t - Servomotor stroke time
)sdnoceS( 03 = 45MQS ;05MQS ;04MQS ;01MQS ;03MTS ;33LQS
STA12B3.41; SQN30.251; SQN72.4A4A20 = 12 (Seconds) (**) Out 4 … on Display led °4 must be switched on, otherwise change the io4.F parameter value from "on" to "out4",
confirm the value, quit the configuration mode then change again the io4.F parameter value from "out4" to "on".
(***) Factory settings. These values must be adapted to machine conditions
N.B. For pressure probe, SP, SPHL, SPLL parameters values are expressed in Kpa (1 bar = 100 Kpa).
