M12927CA
C 8 oPE Safety output value -100... 100 0
C 9 io4.F I/O4 function selection on = Out4 will be ever ON (used as a transmitter
power supply) ,out4 = Uscita 4 (Used as digital
output 4), dG2c = Digital input 2 for contact
closure, dG2U = Digital input 2 driven by 12... 24
VDC
on
C 10 diF1 Digital input 1 function oFF = Not used,
1 = Alarm reset,
2 = Alarm acknowledge (ACK),
3 = Hold of the measured value,
4 = Stand by mode,
5 = Manual mode,
6 = HEAt with SP1 and CooL with SP2,
7 = Timer RUN/Hold/Reset,
8 = Timer Run,
9 = Timer Reset,
10 = Timer Run/Hold,
11 = Timer Run/Reset,
12 = Timer Run/Reset with lock,
13 = Program Start,
14 = Program Reset,
15 = Program Hold,
16 = Program Run/Hold,
17 = Program Run/Reset,
18 = Sequential SP selection,
19 = SP1 - SP2 selection,
20 = SP1... SP4 binary selection,
21 = Digital inputs in parallel
19
C 12 di.A Digital Inputs Action
(DI2 only if configured)
0 = DI1 direct action, DI2 direct action
1 = DI1 reverse action, DI2 direct action
2 = DI1 direct action, DI2 reverse action
3 = DI1 reverse action, DI2 reverse action
0
Out GROUP- Output parameters
Liv N° Param Description
V
alues Default
C 14 o1F Out 1 function AL = Alarm output AL
C 15 o1AL Initial scale value of the analog retransmission -1999 ... Ao1H 1
C 18 o1Ac Out 1 action dir = Direct action
rEU = Reverse action
dir.r = Direct with reversed LED
ReU.r = Reverse with reversed LED
rEUr.r
C 19 o2F Out 2 function H.rEG = Heating output H.rEG
C 21 o2Ac Out 2 action dir = Direct action
rEU = Reverse action
dir.r = Direct with reversed LED
ReU.r = Reverse with reversed LED
dir
C 22 o3F Out 3 function H.rEG = Heating output H.rEG
C 24 o3Ac Out 3 action dir = Direct action
rEU = Reverse action
dir.r = Direct with reversed LED
ReU.r = Reverse with reversed LED
dir
AL1 GROUP - Alarm 1 parameters
Liv N° Param Descrizione
V
alues Default
C 28 AL1t Tipo allarme AL1 nonE = Alarm not used
LoAb = Absolute low alarm
HiAb = Absolute high alarm
LHAo = Windows alarm in alarm outside the
windows
LHAI = Windows alarm in alarm inside the
HidE
9
