M12927CA
windows
SE.br = Sensor Break
LodE = Deviation low alarm (relative)
HidE = Deviation high alarm (relative)
LHdo = Relative band alarm in alarm out of the
band
LHdi = Relative band alarm in alarm inside the
band
C 29 Ab1 Alarm 1 function 0... 15
+1 = Not active at power up
+2 = Latched alarm (manual reset)
+4 = Acknowledgeable alarm
+8 = Relative alarm not active at set point change
0
C 30 AL1L -- For High and low alarms, it is the low limit
of the AL1 threshold;
-- For band alarm, it is low alarm threshold
-1999... AL1H (E.U.) -199.9
C 31 AL1H -- For High and low alarms, it is the high
limit of the AL1 threshold;
-- For band alarm, it is high alarm threshold
AL1L... 9999 (E.U.) 999.9
O 32 AL1 AL1 threshold AL1L... AL1H (E.U.) See
page 7
O 33 HAL1 AL1 hysteresis 1... 9999 (E.U.) See
page 7
C 34 AL1d AL1 delay 0 (oFF)... 9999 (s) oFF
C 35 AL1o Alarm 1 enabling during Stand-by mode and
out of range conditions
0 = Alarm 1 disabled during Stand by and out of
range
1 = Alarm 1 enabled in stand by mode
2 = Alarm 1 enabled in out of range condition
3 = Alarm 1 enabled in stand by mode and in
overrange
condition
1
GRUPPO AL2 - parametri allarme 2
Liv N° Param Description
V
alues Default
C 36 AL2t Alarm 2 type nonE = Alarm not used
LoAb = Absolute low alarm
HiAb = Absolute high alarm
LHAo = Windows alarm in alarm outside the
windows
LHAI = Windows alarm in alarm inside the
windows
SE.br = Sensor Break
LodE = Deviation low alarm (relative)
HidE = Deviation high alarm (relative)
LHdo = Relative band alarm in alarm out of the
band
LHdi = Relative band alarm in alarm inside the
band
SE.br
C 37 Ab2 Alarm 2 function 0... 15
+1 = Not active at power up
+2 = Latched alarm (manual reset)
+4 = Acknowledgeable alarm
+8 = Relative alarm not active at set point change
0
C 42 AL2d AL2 hysteresis 0 (oFF)... 9999 (s) oFF
C 43 AL2o Alarm 2 enabling during Stand-by mode and
out of range conditions
0 = Alarm 2 disabled during Stand by and out of
range
1 = Alarm 2 enabled in stand by mode
2 = Alarm 2 enabled in out of range condition
3 = Alarm 2 enabled in stand by mode and in
overrange
condition
0
10
