Unigas G400A - Page 200

7
ConF > InP >InP2
Input 2 : this input can be used to specify an external setpoint or carry out setpoint shifting
(bold = factory settings)
ConF > InP >InP3
Input 3: this input is used to acquire the outside temperature
(bold = factory settings)
Parameter Value Description
FnC2 0
1
2
3
0=
no function
1= external setpoint (display SPE)
2 =setpoint shifting (display dSP)
3 = angular positioning feedback
SEn2
ti
sensor type input 2
1 0 ÷ 20mA
2 4 ÷ 20mA
3 0 ÷ 10V
40 ÷ 5V
51 ÷ 5V
1 0 ÷ 20mA
OFF2
Sensor offset
-1999..0.. +9999
Correction value measured by the sensor
SCL2
scale low level
-1999..0.. +9999
minimum scale value(for input ohm, mA, V)
SCH2
scale high level
-1999..100.. +9999
maximum scale value(for input ohm, mA, V)
dF2
digital filter
0…2…100
Is used to adapt the digital 2nd order input filter (time in s; 0 s = filter off)
Parameter Value Description
SEn3
sensor type input 3sensor
type input 2
00 =
11 = wire
22 = wire
OFF3
Sensor offset
-1999..0.. +9999
Correction value measured by the sensor
dF3
digital filter
0…1278…1500
Is used to adapt the digital 2nd order input filter (time in s; 0 s = filter off)
