Unigas G400A - Page 208

15
Configuration level
Remote operation
Legend
* = Local
** = Controller OFF
Address Access Data type Signal reference Parameter
0x3426 R/W Float SCL1 Start of display input 1
0x3428 R/W Float SCH1 End of display input 1
0x3432 R/W Float SCL2 Start value input 2
0x3434 R/W Float SCH2 End value input 2
0x3486 R/W Float SPL Start of setpoint limitation
0x3488 R/W Float SPH End of setpoint limitation
0x342A R/W Float OFFS1 Offset input E1
0x3436 R/W Float OFFS2 Offset input E2
0x343A R/W Float OFFS3 Offset input E3
0x1063 R/W Word FnCt Ramp function
0x1065 R/W Float rASL Ramp slope
0x1067 R/W Float toLP Tolerance band ramp
0x1069 R/W Float rAL Limit value
0x1075 R/W Float dtt Remote Detection Timer
0x1077 R/W Float dF1 Filter constant input 1
0x1079 R/W Float dF2 Filter constant input 2
0x107B R/W Float dF3 Filter constant input 3
0x107D R/O Float oLLo Lower working range limit
0x107F R/O Float oLHi Upper working range limit
0x106D R/W Word FnCt Alarm relay function
0x106F R/W Float AL Alarm relay limit value (limit value alarm)
0x1071 R/W Float HYSt Alarm relay hysteresis
Address Access Data type Signal reference Parameter
0x0500 R/W Word REM Activation remote operation *
0x0501 R/W Word rOFF Controller OFF in remote setpoint **
0x0502 R/W Float rHYS1 Switch-on threshold remote
0x0504 R/W Float rHYS2 Switch-off threshold down remote
0x0506 R/W Float rHYS3 Switch-off threshold up remote
0x0508 R/W Float SPr Setpoint remote
0x050A R/W Word RK1 Burner release remote operation
0x050B R/W Word RK2 Relay K2 remote operation
0x050C R/W Word RK3 Relay K3 remote operation
0x050D R/W Word RK6 Relay K6 remote operation
0x050E R/W Word rStEP Step-by-step control remote operation
0x050F R/W Float rY Angular positioning output remote operation
0x0511 R/W Float rHYS4 Switch-on threshold remote (cooling)
0x0513 R/W Float rHYS5 Switch-off threshold down remote (cooling)
0x0515 R/W Float rHYS6 Switch-off threshold up remote (cooling)
