No. Part No. Code Name Picture Qty Note
10 C146-250-000 20101000116
Cross
recessed pan
head screw
32
To install L&R
windows
11 C146-251-000 20101040011
Hexagon
socket
button head
screws
8
To install the
ball track
12 C146-252-000 20101100020
Cross
recessed pan
head screw
16
To install
middle L/R part
13 C146-253-000 20101000117
Cross
recessed pan
head screw
12
To install L/R
side bar
14 C146-254-000 20104020002
Cross
recessed
hexagon
screw kit
6
To install send
ball assy. and
back bottom
plate
15 C146-255-000 20104020004
Cross
recessed
hexagon
screw kit
16
To install
middle bottom
part and Large
marquee
16 C146-256-000 20101108005
Hexagon
socket
button head
screws
2
To install the
front marquee
17 C146-257-000 20102020030
Hexagon
flange nut
4
To install L/R
baffle
18 C146-740-002 20511702026B Steps label / 1
/
