9. OVERALL CONSTRUCTION
9.1 Front Part
No. Part No. Code No. Name Qty
1 C146-728-000 20511702014 Control panel decal 1
2 C146-137-000 2021 1702091 Front door L bracket 1
3 C146-136-000 20211702090 Front door R bracket 1
4 C146-449-000 22003080001 5630 light 1
5 C146-475-000 25300172001 Lock 1
6 C146-147-000 202 11702028 Coin box 1
7 C146-134-001 20211702023A Coin slot 1
8 C146-131-000 20211702089 Power supply fix bracket 1
9 C146-107-000 26000044000 Meter bracket 1
10 C146-102-000 26000006000 Ticket box 1
11 C146-422-000 22301000002 Coin mech 1
12 C146-108-000 26000051000 Ticket cover 1
13 C146-423-000 23100000005 Ticket dispenser 1
14
C146-605-000 20611702002 Control panel L side plastic 1
C146-606-000 20611702003 Control panel R side plastic 1
