UNIS Coconut Bash - Middle Part

Coconut Bash
46
12/14/2018
9.2 Middle Part
No. Part No. Code No. Name Qty
1 C146-220-000 20211702063 Middle support plate 2
2 C146-113-000 20211702006 Bottom middle connect plate 2
3 C146-222-000 20211702065 T molding 2
4 C146-219-000 20211702062 Middle connect plate 2
5 C146-115-000 20211702008 Middle back connect plate 2
6 C146-221-000 20211702064 Middle reinforced plate 2
7 C146-109-00 1 20311702044 Middle top cover plate 1
