UNIS Coconut Bash - Wiring Diagram

Coconut Bash
68
12/14/2018
No. Part No. Code No. Name Qty
1
C146-450-000 22003080017 5630 light 1
C146-451-000 22003080018 5630 light 1
C146-444-000 22002016026 IC2811 light 2.5
C146-440-000 29741614004 4 bit display 1
2 C146-453-000 22003130002 JN55 light 34
3 C146-438-000 29741213010 PCB board 1
4
C146-448-000 22003080003 5630 light 4
C146-447-000 22003080004 5630 light 2
C146-445-000 22002013002 RGB light 2.5
C146-439-000 29741112002 Display 1
5 C146-439-000 29741112002 Display 1
6
C146-445-000 22002013002 RGB light 9.8
C146-429-000 29711702001 5050 light board 7
7 C146-429-000 29711702001 5050 light board 3.5
8 C146-449-000 22003080001 5630 light 1
9 C146-429-000 29711702001 5050 light board 2.5
