UNIS Coconut Bash - Send Ball Assembly

Coconut Bash
50
12/14/2018
9.5 Send Ball Assembly
No. Part No. Code No. Name Qty
1 C146-186-000 20211702116 Driven synchronous wheel 1
2 C146-187-000 20211702117 Driving synchronous wheel 1
3 C146-176-000 20211702035 R baffle 2 1
4 C146-181-000 20211702102
T
op motor fix plate 1
5 C146-175-000 20211702034 R baffle 1 1
6 C146-483-000 20104000042 hexagon bolt 2
7 C146-467-000 20 106080316 BR 2
8 C146-189-000 20211702084 Connect axle 1
9 C146-182-000 20211702040 Driving wheel 1
10 C146-470-000 23404000238 DC moto r 1
11 C146-465-000 20106000320 Flange BR 8
12 C146-178-000 20211702037 Roller 2
13 C146-180-000 20211702039 Connect plate 1
14 C146-177-000 20211702036 Reinforced plate 2
15 C146-616-000 20611702011 Ball belt 1
