Coconut Bash
32
12/14/2018
6. IO SETTING
INPUT:
INPUT Content INPUT Content INPUT Content
IN1 1 Pole score sensor IN9 5 Pole score sensor IN17 Start btn
IN2 1Poleresetsensor IN10 5Poleresetsensor IN18 Anti-cheating sensor 18
IN3 2 Pole score sensor IN11 6 Pole score sensor IN19 Ball out sensor(Front)
IN4 2Poleresetsensor IN12 6Poleresetsensor IN20 Ball out sensor(Back)
IN5 3 Pole score sensor IN13 7 Pole score sensor IN21 Anti-cheating sensor21
IN6 3Poleresetsensor IN14 7Poleresetsensor IN22 An ti-cheating sensor21
IN7 4 Pole score sensor IN15 Send ball sensor IN23
IN8 4Poleresetsensor IN16 Bonus wheel sensor IN24
INPUT Content
J25-T1_IN Tik feedback
J25-T2_IN
J27-C_IN1 Coin mech.
J27-C_IN2 DBV
J26-KEY1 Settings btn
J26-KEY2 Test btn
J26-KEY3 Reset btn
J26-KEY4
Note:IN1 - IN24---Standard input；IN25 - IN32---Fix input
OUTPUT:
OUTPUT Content OUTPUT Content OUTPUT Content
OUT1 1PoleR OUT9 3PoleB OUT17 Out of tik light
OUT2 1PoleG OUT10 4PoleR OUT18 Start btn light
OUT3 1PoleB OUT11 4PoleG OUT19 Send ball motor
OUT4 2PoleR OUT12 4PoleB OUT20 Shake ball motor
OUT5 2PoleG OUT13 5PoleR OUT21 Wheel point
OUT6 2PoleB OUT14 5PoleG OUT22
OUT7 3PoleR OUT15 5PoleB OUT23
OUT8 3PoleG OUT16 6PoleR OUT24
