UNIS Coconut Bash - Expansion Board Output

Coconut Bash
12/14/2018
33
OUTPUT Content
OUT25
J25-T2_OUT
J25-T1_OUT Tik drive
J26-CNT3
J26-CNT2 Tik meter
J26-CNT1 Coin meter
J27-C_CLK2
J27-C_CLK1 Lock coin signal
Note:OUT1 - OUT8IRF540---Output OUT9 - OUT16 TIP12---Output OUT17
-OUT32ULN280---Output, OUT26 - OUT32---fix output
Expansion Board output:
OUTPUT Content OUTPUT Content OUTPUT Content
OUT33 Wheel light R OUT41 OUT49 1 Pole motor
OUT34 Wheel light G OUT42 OUT50 2 Pole motor
OUT35 Wheel light B OUT43 OUT51 3 Pole motor
OUT36 Ctrl panel light R OUT44 6PoleG OUT52 4 Pole motor
OUT37 Ctrl panel light G OUT45 6PoleB OUT53 5 Pole motor
OUT38 Ctrl panel light B OUT46 7PoleR OUT54 6 Pole motor
OUT39 Wheel light OUT47 7PoleG OUT55 7 Pole motor
OUT40 OUT48 7PoleB OUT56
OUTPUT Content
OUT57
OUT58
OUT59
OUT60
OUT61
OUT62
OUT63
OUT64
Note:OUT33 - OUT48TIP12---Output OUT49 - OUT64UNL2803---Output
