9.3 Back Part
No. Part No. Code No. Name Qty
1 C146-119-000 20211702012 Bottom fix bracket 1
2 C146-607-000 2061170201 6 Baffle 1
3 C146-10 1 -000 20211603D104A Relay bracket 1
4 C146-128-000 20211702086 Power supply bracket 1
5 C146-127-000 20211702020 Small ball plate 1
6 C146-126-000 20211702019 Anti-ball blocking plate 1
7 C146-117-000 20211702010 Ball track bottom fi
x
plate 1
8 C146-124-000 20211702017 L ball plate 1
9 C146-125-000 20211702018 R ball plate 1
10 C146-133-000 20211702022 R baffle 1
11 C146-613-000 20611702010 Ball block bracket 7
12 C146-132-000 20211702021 L baffle 1
13
C146-111-001 20211702002A Stair top cover plate 1
C146-112-001 20211702003A Stair bottom cover plate 1
14 C146-715-000 20511702002 Turnplate cover decal 1
15 C146-604-000 20611702001
T
urnplate plastic 1
16 C146-714-000 2051170200 1 Main decal 1
