Unitech HT682 User Manual

9
Then, Connect the USB/Charging Cable to the HT682 and connect the AC adapter to the
cable’s power jack and an electrical outlet. To connect the USB cable to the PDA Scanner:
1. Hold the PDA Scanner face up;
2. Face the side of the connector with the smaller pillar up, as shown below; and
3. Connect.
Or place the HT682 into the Docking Station (first connect the power supply to the Docking
Station).
First Time to Charge the Main Battery & Backup Battery
We would like to propose to charge the battery at least up to 16 hours for the first time to use.
While it normally only takes about 4 hours to charge the battery after it's been drained, when
charging the battery for the first time please allow at least 16 hours. While charging the main
battery the backup battery should also be charged. Please make sure the backup battery has
been switched “ON” (this cannot be emphasized enough).
CAUTION: There is a high risk of data loss from RAM if the backup battery is not fully charged.
This can happen if the main battery has been drained and the unit is not connected
to the AC adaptor. For this reason, it is crucial that the backup battery is switched
on before charging the main battery for the first time.
Protective Screen Film
To protect screen, the HT682 has been provided with a protective plastic film. You may remove
it (if required). The screen will be more susceptible to scratching without the film, but will be
more readable.
First Time Use of the HT682
Pressing the Power ON/OFF Key
The Unitech HT682 welcome screen appears. The Windows CE screen will appear shortly
thereafter.

Unitech HT682 Specifications

General

Certification	CE, FCC, BSMI, VCCI, CCC, SRRC, RoHS
Product color	Black
LED indicators	Yes
Phone function	-
Keyboard layout	Alphanumeric
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 32, Code 39, Code 93, EAN-13, EAN-8, MSI, PLANET, POSTNET, U.P.C.
International Protection (IP) code	IP65
2D (matrix & stacked) barcodes supported	Aztec Code, Codablock, Code 49, Composite Codes, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code
Display diagonal	2.8 \
Display resolution	- pixels
Speakers	Mono
ROM capacity	512 MB
Internal memory	0.512 GB
Internal memory type	SDRAM
Compatible memory cards	SDHC
Maximum memory card size	32 GB
Processor family	OMAP AM3703
Processor frequency	0.8 GHz
USB 2.0 ports quantity	1
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Battery capacity	- mAh
Data network	EDGE, GPRS, GSM, HSDPA, UMTS
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	2.1+EDR
GSM bands supported	850, 900, 1900, 2100 MHz
Security algorithms	AES, EAP-FAST, EAP-TLS, EAP-TTLS, PEAP, WEP, WPA, WPA2
Operating system installed	Windows Embedded Compact Professional 6.0 R3

Weight and Dimensions

Depth	30 mm
Width	55 mm
Height	170 mm
Weight	- g
