Unitech HT682 User Manual

Backlight Setting
The backlight for color display is user-defined. There are two tabs – one for Battery Power and
the other for External Power.
Field Description
Dim Backlight if Select how many minutes you want to elapse before the
backlight dims.
Turn Off Backlight if Select how many minutes you want to elapse before the
backlight automatically turns off.
Turn on Backlight Select this option if you want the backlight to turn on
when the button is pressed or the touch screen is tapped.
Warm Boot / Cold Boot
Warm Boot
Warm Boot is a reset to re-boot the HT682 without losing saved data. Perform a warm boot
when:
 The PDA Scanner fails to respond.
 After installing some software applications
 After making changes to certain system settings, such as network cards
WARNING - Performing a Warm Boot will result in the loss of all unsaved data!
20

Unitech HT682 Specifications

General

Certification	CE, FCC, BSMI, VCCI, CCC, SRRC, RoHS
Product color	Black
LED indicators	Yes
Phone function	-
Keyboard layout	Alphanumeric
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 32, Code 39, Code 93, EAN-13, EAN-8, MSI, PLANET, POSTNET, U.P.C.
International Protection (IP) code	IP65
2D (matrix & stacked) barcodes supported	Aztec Code, Codablock, Code 49, Composite Codes, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code
Display diagonal	2.8 \
Display resolution	- pixels
Speakers	Mono
ROM capacity	512 MB
Internal memory	0.512 GB
Internal memory type	SDRAM
Compatible memory cards	SDHC
Maximum memory card size	32 GB
Processor family	OMAP AM3703
Processor frequency	0.8 GHz
USB 2.0 ports quantity	1
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Battery capacity	- mAh
Data network	EDGE, GPRS, GSM, HSDPA, UMTS
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	2.1+EDR
GSM bands supported	850, 900, 1900, 2100 MHz
Security algorithms	AES, EAP-FAST, EAP-TLS, EAP-TTLS, PEAP, WEP, WPA, WPA2
Operating system installed	Windows Embedded Compact Professional 6.0 R3

Weight and Dimensions

Depth	30 mm
Width	55 mm
Height	170 mm
Weight	- g
