Page B.6
B.6 Code 128 / MSI Code / Code 93 / Codabar/ Label Code:
Enter Group 6 Group Default
0
1
2
3
4
5
6
7
8
9
Code 128:
0/1 -- Disable/Enable
1-64 -- Min Length 1 / Max Length 64
MSI /Pleasey Code:
0/1 -- Disable/Enable
2/3 -- Check Digit Send / No Send
4 -- Check Digit Double Module 10
5 -- Check Digit Module 11 plus 10
6 -- Check Digit Single Module 10
1-16 -- Min Length 1 / Max Length 16
Code 93:
0/1 -- Disable/Enable
1-48 -- Min Length 1 / Max Length 48
Code 11: (Special)
0/1 -- Disable/Enable
2/3 -- One / Two Check Digit
4/5 -- Check Send / No Send
1-48 -- Min Length 1 / Max Length 48
Codabar:
0/1 -- Disable/Enable
2/3 -- Start & Stop Send / No Send
4 -- Check Digit Calculate & Send
5 -- Check Digit Calculate but not Send
6 -- Check Digit not Calculate
7/8 -- CLSI Format On / Off
3-48 -- Min Length 3 / Max Length 48
Label Code IV and V:
0/1 -- Disable/Enable
2/3 – Checksum send/ No send
Min Length
MM
G1
G2
G3
G4
G5
G6
Max Length
NN
Exit
To Next Page
