Unitech PA500 User Guide

Chapter 3 Getting Connected34
Infrared Connection
The infrared (IR) port allows you to synchronize information with an
infrared-enabled computer. Simply align the infrared port of your device
with that on the computer. This method is ideal for quickly switching
between multiple devices since there are no cables or adapters to change.
1 Perform the steps below on your computer.
(1) Configure an infrared port on your computer following the
manufacturer’s instructions.
(2) Once your computer’s IR port is ready, open ActiveSync.
(3) Click File, then Connection Settings.
(4) Under the “In the Allow serial cable or infrared connection to this
COM port” list, select Infrared Port (IR).
(5) Click OK.
2 Perform the steps below on your device.
(1) Align the IR port of your device with that on your computer so that
they are unobstructed and within close range.
(2) Initiate connection by tapping Start > ActiveSync > Menu >
Connect via IR.
(3) Tap Sync.

Unitech PA500 Specifications

System Memory

SDRAM	64 MB
Flash ROM	64 MB

Display

display resolution	240x320 QVGA
display type	Color Transflective TFT
touch screen	yes

Laser Bar Code Scanner

scan rate	104 scans/sec ± 12 scans/sec
scan angle default	47°±3°
scan angle reduced	35°±3°

Power

main battery voltage	3.7 V
main battery capacity	2200 mAh
rechargeable time	3.5 hours

Operating Environment

operating temperature	32°F to 122°F (0°C to 50°C)
storage temperature	-4°F to 140°F (-20°C to 60°C)
relative humidity	5% ~ 95% (non-condensing)

Weight and Dimensions

weight with battery and scan engine	Under 213 g
length	126 mm
height	23 mm
