Unitronics Vision V280 User Manual

V230/280/290
14
Unitronics
Program
Application memory
1MB
Operand type
Quantity
Symbol
Value
Memory Bits
4096
MB
Bit (coil)
Memory Integers
2048
MI
16-bit signed/unsigned
Long Integers
256
ML
32-bit signed/unsigned
Double Word
64
DW
32-bit unsigned
Memory Floats
24
MF
32-bit signed/unsigned
Timers
192
T
32-bit
Counters
24
C
16-bit
Data Tables
120K (dynamic)/192K (static)
HMI Displays
Up to 255
Scan Time
30μsec per 1K of typical application
Communication
Serial Ports
2. See Note 1
RS232
Galvanic isolation
No
Voltage limits
20V absolute maximum
Baud rate range
COM1
COM2
300 to 57600 bps
300 to 115200 bps
Cable length
Up to 15m (50′)
RS485
Galvanic isolation
No
Voltage limits
−7 to +12V differential maximum
Baud rates
300 to 115200 bps
Nodes
Up to 32
Cable type
Shielded twisted pair, in compliance with EIA RS485
Cable length
Up to 1200m (4000′)
CANbus port
1
Nodes
CANopen
Unitronics’ CANbus protocols
127
60
Power requirements
24VDC (±4%), 40mA max. per unit
Galvanic isolation
Yes, between CANbus and controller
Cable length/baud rate
25 m
100 m
250 m
500 m
500 m
1000 m*
1000 m*
1 Mbit/s
500 Kbit/s
250 Kbit/s
125 Kbit/s
100 Kbit/s
50 Kbit/s
20 Kbit/s
* If you require cable lengths over 500
meters, contact technical support.
Optional port
User may install an additional port, available by separate order.
Available port types are: RS232/RS485, and Ethernet.
Notes:
1. COM1 supports RS232 only.
COM2 may be set to either RS232/RS485 according to jumper settings as shown in the product’s
Installation Guide. Factory setting: RS232.

Unitronics Vision V280 Specifications

General

Brand	Unitronics
Model	Vision V280
Category	Controller
Language	English
